NavSource Online: Amphibious Photo Archive

USS LST-264

International Radio Call Sign:
November - Golf - Lima - Zulu
NGLZ

Awards, Citations and Campaign Ribbons

Precedence of awards is from left to right
American Campaign Medal - Europe-Africa-Middle East Campaign Medal (1) - World War II Victory Medal

LST-1 Class Tank Landing Ship:

Laid down, 21 September 1942, at American Bridge Co., Ambridge, PA.

Launched, 13 March 1943

Commissioned USS LST-264, 16 July 1943, LT. R. W. Dale, Jr., USNR, in command

During World War II USS LST-264 was assigned to the Europe-Africa-Middle East Theater and participated in the following campaign:

Campaign and Dates
Europe-Africa-Middle East Campaign
Invasion of Normandy, 6 to 25 June 1944

Decommissioned, 11 January 1946

Struck from the Naval Register, 19 June 1946

Final Disposition, sold for conversion to non-self-propelled mercantile operation, 23 April 1948, to Newport News Shipbuilding and Drydock Co., Newport News, VA.

USS LST-264 earned one battle star for World War II service

Specifications:

Displacement

1,625 t.(lt)

4,080 t.(fl) (sea-going draft w/1675 ton load)

2,366 t. (beaching displacement)

Length 328' o.a.

Beam 50'

Draft

light 2' 4" fwd, 7' 6" aft

sea-going 8' 3" fwd, 14' 1" aft

landing 3' 11" fwd, 9' 10" aft (landing w/500 ton load)

limiting 11' 2"

maximum navigation 14' 1"

Speed 11.6 kts. (trial)

Endurance 24,000 miles @ 9kts. while displacing 3960 tons

Complement

13 officers

104 enlisted

Troop Accommodations

16 officers

147 enlisted

Boats 2 LCVP

Cargo Capacity (varied with mission - payloads between 1600 and 1900 tons)

Typical loads

One Landing Craft Tank (LCT), tanks, wheeled and tracked vehicles, artillery, construction equipment and military supplies. A ramp or elevator forward allowed vehicles access to tank deck from main deck

Additional capacity included sectional pontoons carried on each side of vessel amidships, to either build Rhino Barges or use as causeways. Married to the bow ramp, the causeways would enabled payloads to be delivered ashore from deeper water or where a beachhead would not allow the vessel to be grounded forward after ballasting

Armament (varied with availability when each vessel was outfitted. Retro-fitting was accomplished throughout WWII. The ultimate armament design for United States vessels was

2 - Twin 40MM gun mounts w/Mk. 51 directors

4 - Single 40MM gun mounts

12 single 20MM gun mounts

Fuel Capacity

Diesel 4,300 Bbls

Propulsion

two General Motors 12-567A, 900hp Diesel engines

single Falk Main Reduction Gears

three Diesel-drive 100Kw 230V D.C. Ship's Service Generators

two propellers, 1,700shp

twin rudders

Click On Image For Full Size Image	Size	Image Description	Source
	106k	USS LST-264 moored at Philadelphia in 1942 and open to the public. Probably during a War Bond drive	Mike Murphy
1016026402	106k	USS LST-264 high and dry on the beach at Normandy, circa June 1944.	Mel Bashore for his father LTjg. Lee T. Bashore USS LST-264
1016026408	34k	USS LST-264 high and dry on the beach at Normandy waiting to unload, circa June 1944.	Mel Bashore for his father LTjg. Lee T. Bashore USS LST-264
1016026404	1551k	USS LST-264, crew photo, March 1945.	Mel Bashore for his father LTjg. Lee T. Bashore USS LST-264
1016026406	159k	USS LST-264 crew members, identified as possibly deck crew, date and location unknown.	Mel Bashore for his father LTjg. Lee T. Bashore USS LST-264
1016026407	52k	USS LST-264, officer3s (Lee T. Bashore back row, far left), date and location unknown.	Mel Bashore for his father LTjg. Lee T. Bashore USS LST-264 officers, date and location unknown.
1016026403	511k	USS LST-264, USS LSM(R)-516 tied up at the levee at St. Louis, MO., Tuesday 23 October 1945, for a Navy Day open house.	Mel Bashore for his father LTjg. Lee T. Bashore USS LST-264
1016026409	45k	View from the conning tower of USS LST-264 beached on the ramp of the St. Louis riverfront with USS LSM(R)-516 tied up near the bow of *LST-264* for a Navy Day open house, Tuesday 23 October 1945.	Mel Bashore for his father LTjg. Lee T. Bashore USS LST-264
