Click on thumbnail for full size image |
Size |
Image Description |
Source |
PT-5 |
![PT-5](https://www.navsource.org/archives/12/tn/120500506.gif) |
161k |
c. April 1939 As planned by C & R. Note depth-charge rack between the torpedoes Line drawing by Alan Raven from U.S. Small Combatants: An Illustrated design History |
Robert Hurst |
![PT-5](https://www.navsource.org/archives/12/tn/120500504.gif) |
187k |
28 August 1940 Outboard Profile and Deck Plan |
Historic Naval Ships Association website |
![PT-5](https://www.navsource.org/archives/12/tn/120500502.gif) |
381k |
9 - 10 March 1941 Route and Time Schedule of PT-5 speed run from Pensacola Naval Air Station to Key West Navy Yard. Establishing a speed record for surface craft (25.3 kts.) |
Jerry Gilmartin, MMC, USN, Ret. |
![PT-5](https://www.navsource.org/archives/12/tn/120500503.gif) |
324k |
9 - 10 March 1941 Crew list for speed run |
![PT-5](https://www.navsource.org/archives/12/tn/120500505.gif) |
195k |
15 March 1941 Transverse Sections |
Historic Naval Ships Association website |
RCAF Abadik (B 117) |
![PT-5](https://www.navsource.org/archives/12/tn/120500501.gif) |
198k |
Canadian Forces photo |
Terry Leversedge |
