NavSource Online: Amphibious Photo Archive

USS LSM-499


Awards, Citations and Campaign Ribbons


Precedence of awards is from top to bottom, left to right
Top Row - American Campaign Medal
Bottom Row - Asiatic-Pacific Campaign Medal - World War II Victory Medal - Navy Occupation Service Medal (with Asia clasp)


LSM-1 Class Landing Ship Medium:
  • Laid down, 17 March 1945, at Brown Shipbuilding Co, Houston, TX.
  • Launched 7 April 1945
  • Commissioned USS LSM-499, 14 May 1945, LT. Arland C. Shea USNR in command
  • During World War II USS LSM-499 was assigned to the Asiatic-Pacific Theater:
    LSM Flotilla Sixteen;
    LSM Group Forty-Seven;
    LSM Division Ninety-Five;
  • Following World War II USS LSM-499 was assigned to occupation service in the Far East from 16 September to 10 November 1945
  • Decommissioned, 1 August 1946, at Green Cove Springs, FL.
  • Laid up in the Atlantic Reserve Fleet, Florida Group, Green Cove Springs
  • Struck from the Naval Register, date unknown
  • Sold in January 1959, to Phillips Walker Sales Co., Memphis, TN, converted to a barge
  • Final Disposition, scrapped between 1980 and 1989
    Specifications:
    Displacement 520 t.(light), 743 t. (landing) 1,095 t.(fully loaded)
    Length 203' 6" (ovl)
    Beam 34' 6"
    Draft
    light, 3' 6" forward, 7' 8" aft
    fully loaded, 6' 4" forward, 8' 3" aft
    Speed 13.2 kts. (max.), (928 tons displacement)
    Complement
    5 officers
    54 enlisted
    Armament
    one twin bow mounted 40mm gun
    four single 20mm gun mounts
    Vehicle/Boat Capacity 5 medium or 3 heavy tanks, or 6 LVT's, or 9 DUKW's
    Fuel Capacity
    Diesel 1,225 Bbls
    Troop Accommodations
    2 officers
    46 enlisted
    Armor 10-lb. STS splinter shield to gun mounts, pilot house and conning station
    Endurance 4,900 miles @ 12kts.(928 tons displacement)
    Propulsion
    two General Motors (model GM 16-278A, reversible with hydraulic clutch) Diesel engines, direct drive with 1,440 BHP each @ 720rpm
    Ship's Service Generators
    two Diesel-drive 100Kw 450V A.C.
    one Diesel-drive 20Kw 120V D.C.
    twin propellers, 2,800shp

    >
    Click On Image
    For Full Size Image
    Size Image Description Contributed
    By
    LSM-499 54k USS LSM-499 under way off Okinawa, date unknown. USS LSM / LSMR Association
    LSM-499 54k USS LSM-499 under way, date and location unknown.
    US Naval History and Heritage Command Photo # NH 83281.
    USS LSM / LSMR Association
    LSM-499/440/474 55k USS LSM-440, USS LSM-474, and USS LSM-499, left to right, at Sasebo Harbor, Kyushu, Japan, 23 September 1945. Richard W. Friedrich, F/1c, LSM-467, Collection, slide number 021
    LSM-499 60k USS LSM-499, at Sasebo Harbor, Kyushu, Japan, 22 - 24 September 1945. Hugh L. Hudson, Jr., RM/2c, LSM-467, LSM-49, Collection, Photo 084
    LSM-499
    101449905
    409k Left to Right: USS LSM-253, USS LSM-499, USS LSM-122, Unknown LSM, USS LSM-103, beached at Matsuyama, Skikokyu, Japan, 18 October 1945 Paul Barrett for his father LTjg. Richard L Barrett, USNR USS LSM-499
    LSM-499
    101449908
    266k USS LSM-499 ship's party, circa 1946 Paul Barrett for his father LTjg. Richard L Barrett, USNR USS LSM-499
    LSM-499
    101449906
    221k USS LSM-499 officers, ship's party, circa 1946. Ltjg. Barrett is the officer in khaki uniform. Paul Barrett for his father LTjg. Richard L Barrett, USNR USS LSM-499
    LSM-499
    101449907
    280k USS LSM-499 crew roster, circa 1946Paul Barrett for his father LTjg. Richard L Barrett, USNR USS LSM-499

    The history extract for USS LSM-499 is from LSM-LSMR Amphibious Forces, Vol. II. Paducah, Kentucky: Turner Publishing Company, © 1997. (ISBN 1-56311-389-9).
    Commanding Officers
    01LT. Shea, Arlond Carrol, USNR14 May 1945 - 1 August 1946

    Crew Contact And Reunion Information
    U.S. Navy Memorial Foundation - Navy Log
    USS LSM-LSMR Association
