NavSource Online: Amphibious Photo Archive

USS LST-212

International Radio Call Sign:
November - Foxtrot - Yankee - Zulu
NFYZ

Awards, Citations and Campaign Ribbons

Precedence of awards is from left to right
American Campaign Medal - Europe, Africa, Middle East Campaign Medal (2) - World War II Victory Medal

LST-1 Class Tank Landing Ship:

Laid down, 7 December 1942, at Chicago Bridge and Iron Co., Seneca, IL.

Launched, 12 June 1943

Commissioned USS LST-212, 6 July 1943, LT. Alfred Carr, USN, in command

During World War II, USS LST-212 was assigned to the Europe-Africa-Middle East Theater and participated in the following actions/campaigns:

Campaign and Dates	Campaign and Dates
Europe-Africa-Middle East
Convoy UGS-37, 11 to 12 April 1944	Invasion of Normandy, 6 to 25 June 1944

Decommissioned, date unknown

Struck from the Naval Register, 28 November 1945

Sold for conversion to merchant service, 24 July 1947, to Alfredo A. Lavalle Co., New York, N.Y

USS LST-212 earned two battle stars for World War II service

Specifications:

Displacement

1,625 t.(lt)

4,080 t.(fl) (sea-going draft w/1675 ton load)

2,366 t.

Length 328' o.a.

Beam 50'

Draft

light 2' 4" fwd, 7' 6" aft

sea-going 8' 3" fwd, 14' 1" aft

landing 3' 11" fwd, 9' 10" aft (landing w/500 ton load)

limiting 11' 2"

maximum navigation 14' 1"

Speed 11.6 kts. (trial)

Endurance 24,000 miles @ 9kts. while displacing 3960 tons

Complement

13 officers

104 enlisted

Troop Accommodations

16 officers

147 enlisted

Boats 6 LCVP

Cargo Capacity (varied with mission - payloads between 1600 and 1900 tons)

Typical loads

One Landing Craft Tank (LCT), tanks, wheeled and tracked vehicles, artillery, construction equipment and military supplies. A ramp or elevator forward allowed vehicles access to tank deck from main deck

Additional capacity included sectional pontoons carried on each side of vessel amidships, to either build Rhino Barges or use as causeways. Married to the bow ramp, the causeways would enabled payloads to be delivered ashore from deeper water or where a beachhead would not allow the vessel to be grounded forward after ballasting

Armament (varied with availability when each vessel was outfitted. Retro-fitting was accomplished throughout WWII. The ultimate armament design for United States vessels was

2 - Twin 40MM gun mounts w/Mk. 51 directors

4 - Single 40MM gun mounts

12 single 20MM gun mounts

Fuel Capacity

Diesel 4,300 Bbls

Propulsion

two General Motors 12-567A, 900hp Diesel engines

single Falk Main Reduction Gears

three Diesel-drive 100Kw 230V D.C. Ship's Service Generators

two propellers, 1,700shp

twin rudders

Click On Image For Full Size Image	Size	Image Description		Source
	197k	USS LST-212 crew photo, date and location unknown.		Frederick J. Moisson, Museum of Military History
	147k	USS LST-212 under way, date and location unknown.		Frederick J. Moisson, Museum of Military History

USS LST-212
Dictionary of American Naval Fighting Ships (DANFS)

Commanding Officers
01	LT. Carr, Alfred, USN	6 July 1943 - 8 September 1943
02	LT. Ellis, Mack Donald, USN	8 September 1943 - 1945
03	LTjg. Harris, G. D., USNR	1945 - ?


Courtesy Wolfgang Hechler and Ron Reeves
